AC Motor Run Capacitors - Metallized Polypropylene in a Cylindrical Metal Case
Ducati Metal Case Motor Run Capacitors are certified to EN 60252-1
Standard by VDE and IMQ in compliance with 2002/95 EC ROHS Directive,
and Manufactured under ISO 9002 standards as certified by CSQ.
Equipped with an internal safety protection device in accordance with UL 810
providing Class P2 Protection with a fault current up to 10,000 A.
Self-extinguishing plastic lid (UL94, Class V2)

Series Rated Voltage Lifetime Classification Approved Range Safety Protection Class Data Sheet Request for Quote
4.16.25 425 V 10000 h B 1-35 µF S2 4.16.25.pdf RFQ
400 V 10000 h B 40-60 µF S2
450 V 3000 h C 40-60 µF S2
475 V 3000 h C 1-35 µF S2
4.16.26 425 V 30000 h A 30 -40 µF S2 4.16.26.pdf
RFQ
450 V 30000 h A 0.8-25 µF S2
475 V 10000 h B 30-40 µF S2
500 V 3000 h C 0.8-40 µF S2
4.16.27 330 V 10000 h B 2-60 µF S2 4.16.27.pdf
RFQ
4.16.33 400 V 30000 h A 0.8-10 µF S2 4.16.33.pdf
RFQ
425 V 30000 h A 0.8-40 µF S2
475 V 10000 h B 0.8-70 µF S2
500 V 3000 h C 0.8-40 µF S2

Ducati Full Catalog

AC motor capacitors.pdf
